Description
G18‑series circular LED sports flood light delivers outstanding 180 lm/W high efficiency, adopting premium SMD 5050 LED chips for large‑scale outdoor sports venues. It features precise optical design, scale‑marked adjustable bracket and magnetic aiming position light, enabling fast and accurate high‑mast installation.
Built with electrophoresis outdoor powder‑paint housing, this fixture supports 10KV standard SPD with optional 20KV surge protection. Multiple beam‑angle options (10°/15°/30°/60°) meet diverse layout demands for football, basketball and multi‑sport stadiums. Rich smart control modes including ON/OFF, 0‑10V, DALI, DMX‑RDM and ZigBee are available for venue centralized management.
Rated IP66 waterproof and IK10 impact resistance, it performs stably in extreme‑40℃~+50℃ environments, with over 100,000‑hour service life and 5‑year warranty. Before finalizing power and quantity for your project, confirm required lux, uniformity and CRI for your competition grade. Read our sports venue lighting standard guide to check Class I / II / III sports‑lighting criteria.
Power ranges from 400W‑1200W. Send us your venue parameters, and our engineering team will provide free DIALux lighting simulation and custom layout suggestions.
Specifications
| Power: 400W/500W/600W/800W/1000W/1200W | Input Voltage: AC120~277V/277~480V 50/60Hz |
| Beam Angle: 10°/15°/30°/60° | Effi.: 180Lm/W |
| CCT: 3000K/4000K/5000K/5700K | PF.: >0.9 |
| Impact Resistance Rating: IK10 | CRI:70/80/90 |
| Operating Temp: -40℃~+50℃ | Storage Temp: -40℃~+80℃ |
| SPD: 10KV(Standard) / 20KV(Optional) | Water-proof: IP66 |
| Lifespan: >100,000H | Warranty: 5 Years Warranty |
| Control Optional: ON/OFF / 0-10V / DALI / DMX 512 / ZigBee | Weight: 14.45kg(31.86lbs) |
